2-Channel RF Remote Control Set (VM130) - no limit switch inputs on this board.4 Channel Wireless RF Remote Control Relay Switch Board (3180) - Remotely control 2x DC motors (with limit switch inputs).2-Channel High Current RF Remote Control Relay Board (8157) - Remotely control 1x DC motor (with limit switch inputs).Please check the individual product pages for maximum relay voltage and current rating. Here are some boards that can be used for this set-up. You simply wire the relays as shown in the diagram below (click for larger image in new tab). The 8157 receiver board also includes Reset Inputs so you can incorporate limit switches to prevent motor overrun. If you would like to manually switch the motor direction you can use one of our 2 channel remote control relay boards. Remote Control (RF or IR) DC Voltage / Motor Reversing Switch The motor is connected to the 8045/CT005 relay outputs as per the diagram above. NO and NC are connected respectively to relay positive inputs 1 and 2 on the 8045 or CT005 board and a negative feed is connected to both relay input(-) terminals. 2-Channel SEQUENTIAL Relay Timer Module, 2-45 Minute (CI028)Īn alternative solution would be to drive a 2-channel relay board like 8045 or CT005 using a cyclical timer like VM188.Ī positive feed is taken to the VM188 relay Common terminal.2-Channel SEQUENTIAL Relay Timer Module, 1-180 second (CI027).Please check the individual product page for maximum relay voltage and current ratings and additional timer boards required to repeat the cycle. If you want a motor to automatically switch direction every few seconds to every few hours, we have a few relay boards that will do this for you. Automatic Timed DC Voltage / Motor Reversing Switch Note: Please bear in mind the higher current drawn if the motor is reversed without first being stopped and ensure that it does not exceed the rating quoted for the board. The DC motor will move in one direction when only Relay-1 is ON and in the other direction when only Relay-2 is ON. The motor will be at rest when both relays are OFF or both relays are ON. The approach these solutions use to reverse the polarity of a DC supply voltage employs two SPDT relays that are wired as shown below (click for larger image in new tab). Here you will find some solutions to your needs.

#MOTOR EN PCB WIZARD MANUAL#

From manual push button control to automatic and RF remote control.

motor en pcb wizard

We have a range of boards that allow you to do this automatically or manually. If you need to reverse the direction of a DC motor or the polarity of a DC voltage we have solutions.

motor en pcb wizard

DC Motor Reversing Circuits: Timer or Remote Control
